3-34
(3) Back feed adjustment pattern
Prints a pattern for adjusting a paper back feed amount.
- NORMAL:
Prints the pattern with standard and 4-pass mode.
- H-QUALITY:
Prints the pattern with high quality and 8-pass mode.
- H-DENSITY:
Prints the pattern with high density and 8-pass mode.
- DRAFT:
Prints the pattern with 2-pass mode.
(4) Paper back feed correction value (unit: pulse)
Input a correction value of the paper back feed based on the result
of the back pattern.
±2000 pulse (±5 mm)
1 pulse=2.5µm
# BACK PATTERN
>NORMAL
# BACK ADJUST
>+0000 PULSE
white line = +
overlap = -
- FAST: Prints the pattern with 4 pass mode.
