ENFORCER VIDEO DOOR PHONE
SECO-LARM U.S.A., Inc. 9
Sample Application:
Additional Accessories Available from SECO-LARM:
Door Strikes
(not included)
Connect 2 monitors to 1 or 2 cameras.
Remotely unlock 2 protected entrances.
Extra monitor and camera are easily installed with a
single connection.
DP-121-SQ - Additional Video Door Phone Monitor
DP-121-CQ - Additional Video Door Phone Camera
SECO-LARM carries a complete line of security products.
Please visit www.seco-larm.com for more information.
Screen images simulated
Up to 2 monitors can be connected to 1 or 2 cameras:
The DP-121Q Video Door Phone can be
expanded to connect an additional monitor
and an additional camera.
AC/DC Power
Adapter
(not included)
AC/DC Power
Adapter
(not included)
Camera 1 Camera 2
AC/DC Power
Adapter
(included)
AC/DC Power
Adapter
(included)
Monitor 1 Monitor 2
(optional)
(optional)
