ENFORCER VIDEO DOOR PHONE
2 SECO-LARM U.S.A., Inc.
Camera has 6 LEDs for nighttime
operation.
Remotely and securely talk to visitors and
unlock doors, gates, etc. from the monitor.
Easily connect an additional monitor
and/or an additional camera.
Built-in microphone: Talk and listen to
visitors at the same time.
Camera contains built-in angle
adjustment.
Features
Specifications
Parts List
Overview
Installation Notes
Installation (monitor)
Installation (camera) Operating Instructions
LED Indicator
Dimensions
Sample Application
Additional Accessories
Wiring Diagram
Troubleshooting
Specifications:
Table of Contents
Camera
Type B/W Camera
Chip CCD
Resolution 380 TV lines
Relay output 1 Amp@12VDC max. dry contact
Lens 3.6mm
Min. illumination 0.8 Lux
Weight 8 oz. (220g)
Dimensions
5 1 /
4
" x 3 15 /
16
" x 1 1 /
2
"
(134 x 100 x 38 mm)
Features:
Parts List:
2
2
2
3
4
4
6 7
8
8
9
9
10
12
Simple 4-wire connection.
Easy surface-mount installation.
Camera and monitor turn on and off with
the push of a button.
Camera and monitor turn off automatically
when not in use.
Adjustable contrast, brightness, and ringer
volume.
LED indicators for power and operation.
Monitor
Display CRT
Weight 2 lb. 8 oz. (1.1kg)
Power consumption 800mA@15~18 VDC
Power source 15VDC +/- 15%
Dimensions
9 5 /
8
" x 7 11 /
16
" x 3 1 /
8
"
(245 x 196 x 79 mm)
Camera
Camera bracket
Screws
Screw anchors
Crimp-on terminals
Camera screw
Monitor
Monitor Bracket
AC Power Adapter
Molex wiring harness
x 1
x 1
x 8
x 8
x 6
x 1
x 1
x 1
x 1
x 2
DP-121Q Contains:
Camera
Camera Bracket
Molex wiring harness
Camera screw
Screws
Screw anchors
x 1
x 1
x 1
x 1
x 4
x 4
DP-121-CQ Contains:
Monitor
Monitor Bracket
AC Power Adapter
Molex wiring harness
Screws
Screw anchors
x 1
x 1
x 1
x 1
x 4
x 4
DP-121-SQ Contains:
