Additional Information
37
Specifications
TV System
B/G/H, DK, DVB-T
Colour System
PAL,SECAM
NTSC 3.58, 4.43 (only Video In)
MPEG-2 MP@ML
Channel Coverage
See the ‘Channel Display Table’ below
Picture Tube
KV-32NX200E
FD Trinitron Approx. 82cm
KV-36NX200E
FD Trinitron Approx. 91cm
Sound Output
Left/Right:
2x20W (music power), 2x10W (RMS)
Subwoofer:
1x30W (music power), 1x15W (RMS)
Power Consumption
KV-32NX200E
154W (1w standby)
KV-36NX200E
182W (1w standby)
Dimensions (w x h x d)
KV-32NX200E
Approx. 910 x 445.5 x 590mm
KV-36NX200E
Approx. 1010 x 645 x 607mm
Weight
KV-32NX200E
Approx. 67kg
KV-36NX200E
Approx. 87kg
Rear Terminals
21-pin Euro connector (CENELEC standard) including audio/video
input, RGB input, TV audio/video output.
21-pin Euro connector (CENELEC standard) including audio/video
input, RGB input, TV audio/video output
21-pin Euro connector (CENELEC standard) including audio/video
input, S-video input, selectable audio/video output.
Conditional Access Module
RF In
Audio output - RCA phono jacks
Front Terminals
Video input - phono jack
S video input - 4 pin DIN
Audio inputs - phono jacks
Headphones jack - minijack stereo
Accessories Supplied
RM-939 remote control (1)
IEC designated size AAA (R03) battery (2)
RF Loopthrough cable (1)
Modem (1)
1
2
3/
s
3
4
s
4
4
Design and specification are subject to change without notice
Channel Display Table
Receivable Channels
Channel Displays
B/G/H
E2.12, 21...69
C02.C12, C21...C69
KABEL-TV (1)
S1..S41
S01...S41
KABEL-TV (2)
S01..S05
S42...S46
M1...M10
S01...S10
U1...U10
S11...S20
ITALIEN
A, B.H, H1, H2
C13, C14.C20, C11, C12
D/K
R01.R12, R21.R69
C01...C12, C21...C69
S01...S05
S42...S46
