Page 24
VGF-HS1 3-98-361-11(1)
Suggested network topology : There are some free LAN ports.
Connect your Home Server to one of the free LAN ports.
Home Server
Network router*
LAN ports
Personal computer with
a network (LAN) port
DLNA device with
a network (LAN) port
Personal computer
with wireless LAN
capability
Personal computer with
a network (LAN) port
DLNA device with
a network (LAN) port
Your Home Server can be detected.
There are no restrictions on access to
your Home Server.
Your Home Server cannot
be detected and it is
impossible to access the
content of the Home Server.
Your Home Server cannot be detected.
Your Home Server can be used as a network
storage device if accessed with the IP
address assigned to the Home Server.
Your Home Server cannot be detected by
the Back Up function.
* If your network router has a bridging function, you can enable the function to eliminate the above restrictions
but you may have a problem with the maximum number of connections.
