Sebo G-SERIES - Manual (Page 8)

Page 8
Changing the Micro-Hygiene Filter -
Figure 10
The micro-hygiene filter (31) needs to be changed when
it becomes extremely dirty or clogged with dust, or after
approximately 20 dust bags have been used. To change
the micro-hygiene filter, pull the cover release flap (#5 on
page 5) forward and lift the cover (7) from the dust bag
housing. Then, slide the filter out at the bottom. To
replace, lift the safety lever (32) and slide the new filter in
using the tracks as guides.
Changing the Brush Roller - Figure 12
To change the brush roller (37), push the button (36),
remove the side plate (38), turn the brush clockwise a
quarter of a turn, and pull the old brush roller out. Slide
the new brush roller into the brush housing and turn it
until it locks into position. While slightly pushing the but-
ton (36), press the side plate (38) back into the locked
position.
Figure 9
Figure 10
Figure 11
Figure 12
Always unplug vacuum from outlet
before dismantling any part of the
machine!
!
Dust Bag
Part #5093 AM
Micro-Hygiene
Filter
Part #5036AM
Exhaust Filter
Part #2846
Brush Roller G1
Part #5010AM
Brush Roller G2
Part #2838AM
Changing the Exhaust Filter - Figure 11
After 20 bags have been used, change the exhaust filter
(33). Remove the dust bag housing (6) from the power
head by pressing the housing release button (8). To
remove the exhaust filter, push the catch (34) and remove
the filter cover (35) and exhaust filter. Insert the new filter,
replace the filter cover then insert the dust bag housing
back into the power head.
Maintenance
29
30
7
31
32
35
33
34
Changing the Dust Bag - Figure 9
To change the dust bag, pull the cover release flap forward
(#5 on page 5) and lift the cover (7) from the dust bag
housing. The cover release flap must remain in a for-
ward “pulled-out” position to change dust bags and
lock them into place. Squeeze the clamps on both sides
of the dust bag sealing plate (29), slide the plate from the
holder (30) and push the cap on to seal the bag. Slide the
sealing plate (29) of a new bag into the holder and push it
in firmly. Re-insert cover into dust bag housing, push it for-
ward, then lock it in place by pushing down the cover
release flap. You may find it convenient to store the bag
cap inside the dust bag housing below the dust bag.
36
37
38
