Schwinn 202 - Manual (Page 14)

Assembly Stage #5
Attach Console Mast to Main Unit
31
22
19
27
26
25
29
56
57
30
28
ST
EP
13
33
34
ST
EP
14
58
ST
EP
15
31
tep 13: Run CONSOLE MAST (#30) through the CONSOLE MAST COVER (#27)
nd onto the MAIN UNIT (#31). Before fastening the CONSOLE MAST, attach both
R CABLES (#29 & #26) as well as the COMPUTER CABLE (#28 & #25). To easily
omplete this step it would be helpful to have someone hold the CONSOLE MAST (#30)
nd CONSOLE MAST COVER (#27) while connecting the cables. Fasten with 4
OLTS (#22) and 4 CURVED WASHERS (#19). Tighten with provided Allen wrench.
tep 14: Attach WATER BOTTLE CAGE (#57) to CONSOLE MAST (#30) with
CREWS (#56). Tighten with Phillips head screwdriver.
Assembly Hardware Required: (4) Allen Bolts 16 mm long (item #22)
(4) Curved Washers (item #19)
(4) Computer Screws (item #33)
(2) Water Bottle Cage Screws M5*12 mm (item
#56)
S
a
H
c
a
B
S
S
31
Step 16
