Basic Operations
Basic Operations
TC-WE525/WE425/WR681/3-862-714-21(1)/CED/SP/E2/E3
7 EN
–4
L
R
– ∞ +8 dB +4 0 –10 –20 –30
§
p ª ·
0 )
OFF
0 )
p ª ·
RESET MEMORY RESET MEMORY A B COUNTER
HIGH/NORMAL
DOLBY NR B C
DUBBING A B
START(DECK B P )
AUTO REC LEVEL
FADER ARL
π SYNCHRO
PHONES
§
0
1
2
3
4 5 6
7
8
9
10
P R r
PAUSE REC MUTING REC
REC LEVEL DOLBY NR
5 Press PAUSE P or ·.
Recording starts.
6 Start playing the program source.
z To protect recordings
against accidental erasure
Break out the record-protect
tab(s) (see page 13).
To Press
Stop recording
Start recording from the reverse side ª twice in Step 5
Pause PAUSE P. Press the button again to
resume recording.
Take out the cassette § after stopping recording
Use these switches (controls) to perform additional
operations
p
* HX Pro headroom extension
originated by Bang & Olufsen
and manufactured under license
from Dolby Laboratories
Licensing Corporation.
“DOLBY“, the double-D symbol
a
and “HX PRO” are
trademarks of Dolby
Laboratories Licensing
Corporation.
z The Dolby HX PRO*
system automatically
works during recording
Distortion and noise in the
high-frequency response are
reduced to produce high-
quality sound that can be
enjoyed even during
playback on other tape decks.
To record with the Dolby NR system
Set DOLBY NR to B or C before you start recording.
For type IV tape
For type I or
type II tape
To adjust the recording level manually
After pressing REC r in Step 4 on page 6, turn
REC LEVEL so that the peak level meters reach
the recommended level for the corresponding
tape type. After completing the adjustment, stop
playing the program source, then continue the
procedure from Step 5.
