7
Dome Camera Control
Dome Camera Connection & Settings:
• See section Pin Definition of Alarm I/O & RS-485, and Audio In for RS-485 port pin definition.
• Connect the R+, R- terminals on the dome camera to the D+, D- terminals on the RS-485 port
by RS-485 cable respectively.
• To set up dome camera’s protocol and ID, press MENU to access the OSD main menu or
change the protocol and ID by using SpecoRemote, and select <Camera Setup>. The available
protocols include <Speco>, <DSCP>, <AD422>, <Pelco D>, <Pelco P>, <Fastrax 2>, <JVC>,
<Panasonic_C>, and <Panasonic_N>. The default is <None>. Note that ID number must
match the ID address defined by the dome camera.
• To configure the RS-485 parameters, select <System Setup> from OSD main menu or through
SpecoRemote, and then select <RS485 Setup>. The default RS-485 settings are 9600 Baud, 8
Data Bits, 1 Stop Bit and No Parity.
