Speco Technologies 8WM User Manual
Page 3
3
7
Main Monitor
Audio Out
Main Monitor Audio Out RCA connector is provided for the DVR to connect an audio output
device (e.g. an amplified speaker).
8
Call Monitor
Audio Out
Call Monitor Audio Out RCA connector is provided for the DVR to connect an audio output
device (e.g. an amplified speaker).
9
Audio In
Audio In connectors are for the DVR to connect audio source devices. For DVR-4WM, 4 RCA
Audio In connectors will be provided; whereas for DVR-8WM and DVR-16WM, a D-Sub Audio
In connector is provided.
10 Power Jack
The DVR has a free voltage DC power connection jack. Please connect the power supply
adapter shipped with the unit.
