Sanyo 2000 LUMENS PLC--XL50A - Manual

PLC PLC--XL50A XL50A
2000 LUMENS
z XGA z ULTRA SHORT-THROW PROJECTOR
ULTRA SHORT-THROW PROJECTOR
Resolution XGA (1024 x 768)
Brightness (typical) 2000 Lm
Contrast Ratio (Full on / off) 700:1 Contrast Ratio (Full on / off) 700:1
Image Size 60"-80“
Aspect Ratio 4:3
Projection Lamp 230W
Scanning Frequency H:15-100kHz, V:50-100Hz
Fan Noise 29.0 dBA (Eco)
Voltage 100-240V AC (auto voltage) ; 50/60 Hz
Power Consumption 259W (Eco)
Input signal compatibility UXGA/WXGA/SXGA+/SXGA/XGA/SVGA/VGA/MAC
Color System NTSC/PAL/SECAM/NTSC4.43/PAL-M/PAL-N
Projection Lens (inch) F1.85 f=0.19"
Throw Ratio N/A
Throw Distance (feet) N/A
Zoom / Focus Fixed/Manual
Up / Down Ratio N/A
Digital Keystone Correction V +/- 5°
Digital Zoom 16x - 1x
S k O t t 2W
3LCD Ultra
Short-Throw
ULTRA SHORT-THROW PROJECTOR
To shorten the projection distance of the PLCXL50A, a large
diameter aspheric (non-spherical) lens and high precision aspheric
mirror technology was developed. A optical engine was also
developed, which enables an 80-inch projection from the ultra-short
distance of approximately 3-inches. This creates an opportunity to
project extremely large images in any room or space.
OPTICAL ENGINE FOR VERTICAL AND HORIZONTAL
PROJECTION
Speaker Output 2W
Weight (lbs) 15.9lbs
Dimensions (inch) W,H,D 14.7x 7.8 x 19.5 inch
Replacement Lamp 610 347 8791
Replacement Remote 645 093 7248
Lamp Life * (hours) 3000h (Eco)
PC/Video
D-sub 15 x 2 (RGB, S-Video)
Mini DIN 4pin x 1 (S-Video)
RCA x 3 (Component)
The proprietary optical and cooling technologies used in the PLC-
XL50A allow both vertical and horizontal projection. The optical
engine was created with a high-precision mirror combined with a
distortion correction mechanism lens, enabling large magnification
without distortion, even from ultra-short distances.
PROJECTOR ALLOWING VERSATILE APPLICATIONS
By shortening the distance for projection, the options for installation
are greatly improved, including floor, tabletop and wall mount
projection. The variety of applications is almost limitless, providing
Input
( p )
RCA x 1 (Composite)
Audio
Stereo mini jack x 1
RCA x 2
Output
PC/Video D-sub 15 x 1 (Monitor out)
Audio Stereo mini jack x 1
Other Feature Mini DIN 8pin x 1 (RS232C)
AC power cord x 1
VGA cord x 1
p j y pp , p g
effective, quick and easy presentations or displays. The PLC-XL50A
presents a new avenue for education/instruction, “edutainment,”
specialized business viewing and informational attention-getting
signage.
EASILY ADAPTS TO DIFFERENT PROJECTION SURFACES
Projection surface-oriented features include top and bottom keystone
correction for proper alignment of the projector and a Color Board
Mode, which allows adjustment of the hue when projecting an image
on a color (non-white) surface so that it appears to be projected on a
Included Accessories
VGA cord x 1
Quick reference guide
Owner’s manual x 1 (CD-ROM)
Quick manual x 1
CD-ROM read me note x 1
Remote control x 1 (AA battery x 2)
PIN code Label
Warranty
Three years parts and labor; 90 days original lamp;
Quick Repair Program under warranty
on a color (non white) surface so that it appears to be projected on a
white surface. The additional Black Board Mode enables educational
institutions to use the projector with all standardized educational
boards.
Because its products are subject to continuous improvement, SANYO reserves the right to modify
product our design and specifications without notice and without incurring any obligations.
* Lamp life may vary due to room conditions, usage, and maintenance. The replacement time is a
general estimate. The brightness of a lamp usually decreases over time and use.
©2009 SANYO
Back Panel
