Samsung 242MP - Manual (Page 47)

General
General
Model Name SyncMaster 242MP
LCD Panel
Size 24.0" Diagonal
Display area 518.4(H) x 324(V)
Pixel Pitch 0.270mm (H) x 0.270mm (V)
Type a-si TFT active matrix
Synchronization
Horizontal 31 ~ 81kHz
Vertical 56 ~ 75 Hz
Display Color
16.7M Colors (true 8bit)
Resolution
Optimum resolution WUXGA 1920 x 1200 @60Hz
Maximum resolution WUXGA 1920 x 1200 @60Hz
Input Signal, Terminated
RGB Analog , DVI(Digital Visual Interface) Compliant Digital RGB,
0.7Vp-p± 5%, Positive bright, 75 ohms ±10%(terminated),
Separate H/V sync, Composite,TTL level, positive or negative
TV / Video
Color system NTSC-3.58/4.43 ,PAL-M/N, PAL/SECAM-L/L',B/G,D/K,I
Video format CVBS , S-Video, Component input(Y,Pb,Pr) , SCART input
Maximum Pixel Clock
162 MHz
Power Supply
AC 100 ~ 240 VAC(+/- 10%) , 60/50 Hz ± 3Hz
Signal Cable
15pin-to-15pin D-sub cable, detachable, 1.8m
