4
PRODUCT DIAGRAM (Actual product design may differ slightly from images below)
FRONT
A. Control panel
B. Air outlet
C. Casters
D. Power Cord & Plug
E. Drain Plug
F. HEPA Air Purifier Storage
BACK
A. Hot air outlet grill
B. Lower air inlet grill
C. HEPA Air Purifier Holder
D. HEPA Air Purifier
ACCESSORIES
Flexible exhaust hose with 2 adapters
• 3-piece set
• stretches from 14 1/4” to 60 5/8”
(36cm to 150cm)
Adjustable window slider kit
• 3-piece set
• adjusts 33 1/2” to 81”
Drain tube
Drain pan
A
B
C
E
F
D
A
B
C
D
