Soleus Air PA1-14R-32 - Manual (Page 3)

3
SPECIFICATIONS
• The cooling capacity is measured at an ambient temperature of DB 86 °F, WB 78 °F.
• Noise level is measured at a distance of 3.28 ft away from the front of the unit, when the unit is in cooling mode.
• Power consumption is measured when the fan runs at the highest speed setting.
• These specifications are for reference only. For actual data, please refer to the rating label on the back of the unit.
• If the environment temperature is higher than the max operating temperature or lower than the minimum operating temperature,
the air conditioner may not work properly.
DISCLAIMER
ALL INFORMATION AND THE TECHNICAL SPECIFICATIONS PRESENTED IN THIS USER’S MANUAL ARE THE
PRESENTATION OF THE MANUFACTURER. SOLEUS INTERNATIONAL HAS NOT CONDUCTED INDEPENDENT
TEST TO THE INFORMATION AND THE SPECIFICATIONS PRESENTED HEREWITHIN.
PACKAGE CONTENTS
Portable Air Conditioner
Exhaust Hoses (1)
Hose Adapters (1)
Window Kit Adapter (1)
HEPA Filter (1)
Remote Control
AAA Batteries (2)
Window Kit - 3 Sliding Panels (1 single hose panel, 2 extension panels)
Owner’s Manual
MODEL PA1-12R-32
Cooling Capacity 12,000 BTU/Hr
Heating Capacity 12,500 BTU/Hr
Dehumidifying Capacity 63 pts/day
Air Purifier Capacity Removes 99.97% Microns
Power Consumption
Cooling 1387 Watts
Heating 1180 Watts
Air Flow Volume 265 CFM
Power Source 115 V / 60 HZ
Rated Current
Cooling 12.7 A
Heating 10.8 A
Sound Pressure Level <50db(A)
Weight 86.9 lbs
Dimensions (WxDxH) 17.87”x14.3”x32.1”
Refrigerant R22
PA1-14R-32
14,000 BTU/Hr
14,500 BTU/Hr
63 pts/day
Removes 99.97% Microns
1485 watts
1200 Watts
265 CFM
115 V / 60 HZ
13.6 A
11 A
<50db(A)
86.9 lbs
17.87”x14.3”x32.1”
R22
