REF PART�# DESCRIPTION REF PART�# DESCRIPTION
4 XPB25 HEX�BOLT�3/8-16�X�1�3/4 312 XD3393312 BEARING�BLOCK
5 X1693005 HANDLE�KNOB 313 XD3393313 SPACER
6 X1693006 CRANK�HANDLE 314 XP6200 BALL�BEARING�6200
7 XPN08 HEX�NUT�3/8-16 315 XP6004 BALL�BEARING�6004ZZ
8 XPSS11 SET�SCREW�1/4-20�X�1/4 316 XD3393316 SPACER
301 XD3393301 ACME�SCREW 317 XPSB138M CAP�SCREW�5/16-18�X�3/8
302 XD3393302 ACME�NUT 319 XPB11 HEX�BOLT�5/16-18�X�1-1/2
303 XPSS03 SET�SCREW�1/4-20�X�3/8 320 XPN02 HEX�NUT�5/16-18
304 XPSB30 CAP�SCREW�5/16-18�X�1/2 321 XD3393321 MOUNTING�CLAMP
305 XD3393305 BUSHING 322 XPWR1214 COMBO�WRENCH�12�X�14
306 XD3393306 COMPRESSION�SPRING 323 XPAW04M HEX�WRENCH�4MM
307 XD3393307 EXTENSION�PLATE 324 XPAW06M HEX�WRENCH�6MM
308 XPFH03 FLAT�HD�SCR�1/4-20�X�1/2 325 XD3393325 STUD
309 XD3393309 BASE�PLATE 326 XPN08 HEX�NUT�3/8-16
310 XD3393310 SPECIAL�BOLT�3/8" 327 XPLW04 LOCK�WASHER�3/8
311 XD3393311 PLUNGER
