2. USB FM Radio Player
Figure 2 shows each of the features of the USB FM Radio Player. Additionally, the player includes the following
features:
• Press the desired Station Preset button until a beep is heard to set the button to the current station.
• Press the Seek & Scan button until a beep is heard to begin a scan through all available stations.
• Press the Preset Scan button to scan through the preset stations.
• Press the Configuration Options button to open the Configuration Options window shown in Figure 3.
• Press F1-F12 on the PC keyboard to select the corresponding Station Preset.
• Press the left and right arrow buttons on the PC keyboard to perform seek and scan functions.
• Press the up and down arrow buttons on the PC keyboard to perform tuning functions.
• Hover the mouse over each button to display tooltips and programmed stations.
• Right-click the Silicon Labs USB FM Radio icon in the systray menu to display a list of the station presets as
well as an alternative way to seek and tune the radio.
Figure 2. USB FM Radio Player
Links to Silicon
Laboratories Website
Station Presets
Signal Strength
Stereo/Mono
Control and
Display
Seek & Scan
Controls
RDS Station
Identifier
RDS Display Field
Tuning
Controls
Preset Scan
Configuration
Options
Volume Controls
