3: Choose Correct Mounting Plate
200mm x 200mm
75mm x 75mm or 100mm x 100mm
001482.eps
FPS10 - Star
75mm
75mm
[03]
001482.eps
FPS10 - Star
100mm
100mm
[03]
For monitors with 200mm x 200mm hole
spacing, you must remove the existing plate
from the head assembly [03] and replace it
with plate [02].
NOTE
001489.eps
001490.eps
001490.eps
001420.eps
Arr
ow
s
[03]
[02]
200mm
200mm
001420.eps
