Sanus Systems Accurate Furniture AFV48 - Manual

Assembly Instructions for Model: AFV48
Thank you for choosing Accurate Furniture from Sanus Systems!
Safety Warning: If you do not understand these directions, or have any doubts about the safety of the installation, please call a qualified
contractor or contact Sanus at 800.359.5520 or www.sanus.com. Check carefully to make sure that there are no missing or defective
parts. Our customer service representatives can quickly assist you with installation questions and missing or damaged parts. Replace-
ment parts for products purchased through authorized dealers will be shipped directly to you. Never use defective parts. Improper instal-
lation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified by Sanus Systems.
Sanus Systems can not be liable for damage or injury caused by incorrect mounting, incorrect assembly, or incorrect use. Please call
Sanus Systems before returning products to the point of purchase.
Required Tools:
Supplied Parts and Hardware: Some parts not shown as actual size*
(10) Shelf Connector - a (6) Top Bolt - b (6) Foot - c
(4) Grommet - d (2) Spacer - e (1) Allen Key - f
(4) 7” Pillar - g* (6) 3” Pillar - h* (6) 9” Pillar - i*
(1) Top Shelf - j* (2) Bottom & Middle Shelf - k*
(1) Front Brace - l*
Sanus Systems 2221 Hwy 36 West, Saint Paul, MN 55113 5.27.05
Customer Service: 800.359.5520. See complementary Sanus products at www.sanus.com
Step 5: Add 7” Pillars
Thread a 7” Pillar (g) onto each exposed Shelf Connector (a). Place a Grommet (d) in each wire management hole in the Bottom and
Middle Shelf (k). See Diagram 5 for assistance.
Diagram 5
g
d
a
k
k
Step 6: Add Top Shelf
To add the Top Shelf (j), insert the front two Top Bolts (b) through the holes in the front of the Top Shelf, the Front Brace (l) and thread
them into the 7” Pillars (g). See Detailed View A for assistance. Insert the back two Top Bolts through the holes in the back of the Top
Shelf, the Spacers (e), and thread them into the 7” Pillars. See Diagram View B for assistance. Tighten each Top Bolt with the Allen Key
(f).
Detailed View A Detailed View B
Diagram 6
b b
j j
l e
g g
front
