Sony CRX320AE - Manual

English
Please refer to this manual together with the “ATAPI Interface Drive User’s Guide” in the attached Software
Disc, which carries more detailed information.
Français
Reportez-vous au présent manuel ainsi qu’au document intitulé “Lecteur d'interface ATAPI - Guide de
l’utilisateur” contenu sur le disque du logiciel accompagnant ce produit pour plus de détails.
Deutsch
Einzelheiten entnehmen Sie bitte diesem Handbuch sowie der “Laufwerk mit ATAPI-Schnittstelle -
Anwenderanleitung” auf der mitgelieferten Software-Disc.
Español
Consulte este manual junto con la “Unidad de interfaz ATAPI - Guía del usuario” del disco de software
suministrado, que contiene información más detallada.
Italiano
Fare riferimento al presente manuale insieme a “Guida dell’utilizzatore dell’unità disco con interfaccia ATAPI”
nel disco del software allegato, nel quale sono contenute informazioni più dettagliate.
Português
Consulte este manual juntamente com o “Guia do Utilizador do Drive de Interface ATAPI” incluído no disco
de software fornecido, para obter informações mais detalhadas.
Nederlands
Raadpleeg deze handleiding alsook de “ATAPI Station-interface -Gebruikershandleiding” op de bijgevoegde
Software Disc, die meer gedetaileerde informatie bevat.
Svenska
Förutom denna bruksanvisning finns mer information i “Brukanvisning för enhet med ATAPI gränssnitt” på
den medföljande programskivan.
2-590-609-11(7)
CRX320AE
CD-RW/DVD-ROM
Drive Unit
Package Contents
Please verify that the package includes the following accessories with the drive when
unpacking.
If any of these items appears to be missing or damaged, please contact your supplier.
• CD-RW/DVD-ROM drive • 40-pin ATAPI (IDE) flat cable
• Screws ( ×4)
• Product Information (this document)
• Software Quick Start Guide
• Quick Start Guide (for ATAPI (EIDE) Interface Drive)
• Software disc
• Warranty cards
Note
To guard against possible loss or damage, be sure to make a backup copy of the provided software disc on a CD-R
disc or other media. The software disc is not sold separately.
Please Record Responsibly
Before copying anything onto a CD-R or CD-RW disc, make sure that you are not violating
copyright laws. Most software companies allow you to make a backup or archive copy of
software. Check your software license agreement for details.
 2005 Sony Corporation Printed in China P/N: 7819901429WA
This CD-RW/DVD-ROM drive can be used
in systems with the following capabilities.
❑ CPU: Pentium II 400 MHz or higher is
recommended.
❑ PC/AT-compatible PC
❑ OS:
Windows ® 98 Second Edition
Windows ® 2000 Professional
Windows ® Millennium Edition
Windows ® XP Home Edition
Windows ® XP Professional
❑ 64 MB RAM or higher is recommended
❑ At least 1 GB available hard disk space
❑ One available EIDE (ATAPI) interface
connection with DMA capability
System Requirements
❑ One empty 5-inch half-height drive bay
❑ One available internal +12 V/+5 V power
connector
Notes
• The above system configuration is given as a
minimum requirement for a system on which basic
CD-RW writing performance can be obtained. In
actual use, the requirements for the writing software
and “Windows” also have to be taken into
consideration. (Normally, these requirements will be
higher than the above specifications.)
• The drive cannot be assured to operate properly if
connected to an ATAPI interface adapter card (we
cannot guarantee compatibility or offer user support).
Introduction
This product offers the following features.
❑ An internal CD-RW/DVD-ROM drive
with ATAPI (EIDE) interface for PCs.
❑ Writes up to 52× speed on CD-R disc
media.
❑ Writes up to 32× speed on CD-RW disc
media.
❑ Reads CD-ROM discs at up to 52×
speed.
❑ With the Turbo Boost function, easily
switch from the default 40 × read/write
speed to 52 × speed.*
❑ Reads DVD-ROM discs at up to 16×
speed.
* For details, see “Turbo Boost Function” below.
❑ Features “Power-Burn conformed”
technology to prevent buffer under-run
errors.
“Power-Burn conformed” is used to refer to a
CD-R/RW that uses CD-R/RW recording
technology (ICs and/or firmware) other than
Power-Burn, but provides performance equivalent
to that of Sony original Power-Burn technology
based on the Power-Burn concept.
Notes
• Writing speed may automatically be adjusted
depending on the disc specified speed or disc
conditions such as weight imbalance and eccentricity.
• 1 × and 2× writing speed and discs are not supported.
• During startup, the drive may make a whirring noise
due to balls contained in the spindle motor. This is
normal and does not indicate a drive malfunction.
Safety Regulations
WARNING
You are cautioned that any changes or modifications not expressly approved in this document could void your
authority to operate this equipment.
To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only.
CAUTION:
As the laser beam used in the CRX320AE is harmful to the eyes, do not attempt to disassemble the cabinet.
Refer servicing to qualified personnel only.
The use of optical instruments with this product will increase eye hazard.
The use of controls or adjustments or performance of procedures other than those specified herein may result in
hazardous radiation exposure.
This label is located on the top of the drive unit enclosure.
Dieses Etikett befindet sich an der Oberseite des Laufwerksgehäuses.
The CRX320AE is classified as a CLASS 1 LASER PRODUCT.
The CLASS 1 LASER PRODUCT label is located at the top of the enclosure.
Bei diesem CRX320AE handelt es sich um ein
Laser-Produkt der Klasse 1.
Das Etikett mit der Aufschrift LASER KLASSE 1
PRODUKT befindet sich auf der Oberseite des
Gehäuses.
CE Sicherheitsbestimmungen
Diese Ausrüstung erfüllt die Europäischen EMC-Bestimmungen für die Verwendung in folgender / folgenden
Umgebung(en):
• Wohngegenden
• Gewerbegebiete • Leichtindustriegebiete
(Diese Ausrüstung erfüllt die Bestimmungen der Norm EN55022, Klasse B.)
• Power-Burn and are trademarks of Sony Corporation.
• Pentium is a registered trademark of Intel Corporation.
• Microsoft, MS, MS-DOS and Windows are registered trademarks of Microsoft Corporation.
• Other system and product names used herein are registered trademarks or trademarks of their respective
manufacturers, although the TM and ® marks are not used in the text.
Before using this device, be sure to read the end-user license agreements for the software provided with your
computer.
❑ Our product warranty is valid only when the supplied accessories (including software) are used in the
specified or recommended system environment, in accordance with the documentation, and applies
only to the CD-RW/DVD-ROM drive. Our customer service and user support apply only under these
product warranty conditions.
❑ Please note that we cannot accept responsibility for failure of the computer or other devices,
incompatibility with special hardware, operating problems caused by improper installation of software,
loss of data, discs or other accidental or incidental damage that might occur when using this product.
❑ The guarantee and user support for this product are valid only within the countries or sales regions
specified on the warranty card.
❑ Copyright laws prohibit the copying in part or in full of the supplied software and documentation, or
loaning the software, without obtaining permission of the copyright holder.
❑ We cannot accept responsibility for any direct or indirect financial damage or loss of profit that might
occur when using the supplied software.
❑ The supplied software can only be used with this product.
❑ Specifications of the supplied software may be changed without notice in the interest in product
improvement.
LUOKAN 1 LASERLAITE
KLASS 1 LASER APPARAT
CLASS 1
LASER PRODUCT
LASER KLASSE 1
PRODUKT
Compatible discs
CD-R CD-RW
CD-ROM CD-ROM XA
CD-DA 1) CD Extra (CD+)
Video CD CD TEXT
Photo CD
DVD-ROM
DVD-Video
Disc diameter 12 cm
8 cm (for horizontal use only)
1) This product is designed to playback discs that conform to the Compact
Disc (CD) standard. Recently, various music discs encoded with copyright
protection technologies are marketed by some record companies. Please
be aware that among those discs, there are some that do not conform to the
CD standard and may not be playable by this product.
When you use this unit as an audio CD player, please use compact discs
with the following mark.
Writing Systems
Track-at-once Disc-at-once
Session-at-once Packet writing
Drive
Data transfer rate
CD-ROM 7.8 MB/s (52 × speed) 2) 3)
DVD-ROM 22.1 MB/s (16 × speed) 3)
Access time
Average random stroke CD-ROM
120 ms
DVD-ROM 140 ms
2) When using the Turbo Boost function.
3) The maximum data transfer rate depends on the
capabilities of the host PC.
Please note that specifications and
appearance may be subject to change
without notice.
Buffer under-run error protection
technology
Operating Environment
5 to 40 °C
Power and Miscellaneous
DC +5 V 1.5 A (max.)
DC +12 V 1.5 A (max.)
Size
Approx. 145.8
Ч 41.3 Ч 165 mm (W×H×D)
(excluding front bezel)
Weight
Approx. 0.9 kg (drive only)
Interface
Drive interface
ATAPI (EIDE)-compliant
Drive Inquiry
SONY CD-RW CRX320EE
Buffer capacity
1.5 MB
Laser specifications
Type
CD: RLD78PZW4
DVD: RLD65MZT2
Wavelength
CD: 784 ± 5 nm
DVD: 655 +5/–10 nm
Output power (max.)
CD: 120 mW (CW)
230 mW (Pulse)
DVD: 10 mW
Specifications
The default CD-R and CD-ROM read/write
speed of this drive is 40
× speed. With a
single touch, you can activate the Turbo
Boost function, making the read/write speed
52
× speed.
CAUTION
• On rare occasions, some discs may not be able to
tolerate 52 × speed, causing them to break. We
recommend that you do not use deeply scratched,
brittle, or other discs that may break at 52
× speed.
• The Turbo Boost function does not increase read/write
speed with CD-RW or DVD-ROM discs.
1 Insert a disc into the drive.
The speed when you insert a disc is
normally 40
× speed.
Turbo Boost Function
2 Press the Eject button for five
seconds.
The Busy indicator blinks twice and the
speed switches to 52
× speed. (The Turbo
Boost function is active.)
Notes
• When you want to write at 52 × speed, insert the disc
into the drive, activate the Turbo Boost function, and
then start writing to the disc.
• When writing with the Turbo Boost function, the Busy
indicator blinks more rapidly than usual.
• When you open the disc tray, the speed reverts to its
default of 40 × speed.
• The Turbo Boost function does not guarantee a 52 ×
write speed. Depending on the condition of the disc
you are using, the speed may be lower.
Product Information
Included Documents
❑ Quick Start Guide
❑ Software Quick Start Guide
❑ Electronic manual on the software disc
❑ Warranty cards
❑ Product Information (this document)
DVD region codes
The playback of DVD-Video (DVD discs) is
protected and controlled by a region code
setting. For the drive to play back DVD-
Video, the region code on the DVD disc, the
region code of the drive, and the region code
of the DVD-Video software must all match.
With this drive, the region code can be set up
to five times, including the initial assignment
(RPC phase 2 standard). After setting the
region code five times, the setting becomes
permanent and can no longer be changed.
From this point on, you are only able to play
back DVD-Video whose region code
matches the one set the fifth time.
Do not attempt to make unauthorized
changes to the region code. Any problems
resulting from doing so are not covered by
the warranty.
Hint
You can change the region code of the drive on it’s
properties dialog box accessible from the Device
Manager.
Local technical support is only
available in the specified sales
regions. The customers in these
regions should be provided with a
warranty card for this product.
For contact information, refer to
the warranty card.
Note that technical support
conditions may vary according to
the locality, and that charges and/
or limited service may apply in
some regions.
Technical Support
Please consult the Sony global sites listed
before calling with questions about using
this product, or with technical questions
about the drive or the supplied software. If
using telephone or e-mail support, please
have the following information available:
• Model number: CRX320AE
• Serial number
• Date and place of purchase
• Computer maker and model number
• Computer specifications (CPU speed,
memory size, OS version, etc.)
• Writing software used (version, etc.)
Product and Support Information
Sony Global Sites Information (As of January, 2007)
Product purchased in the USA:*
http://sony.storagesupport.com/
Product purchased in Canada:
http://www.sony.ca/
Product purchased in Australia or New
Zealand:
http://www.sony.com.au/
Product purchased in Europe:*
http://www.sonyisstorage.com/
Product purchased in Hong Kong:*
http://www.sony.com.hk/Electronics/cp
Product purchased in China:*
http://www.sony.com.cn/ed/cp/
Product Purchase in Singapore:
http://www.sony-asia.com/storage/
Product purchased in Taiwan:*
http://www.sony.com.tw/ds/
Product purchased in Korea:*
http://www.sony.co.kr/cp
Product purchased in Brazil:
http://www.sony.com.br/eletronicos
Product purchased in the Middle East:
http://www.sony-mea.com/
* Local Web sites for computer peripheral products
About the Bundled Writing Software
Detailed information about the supplied
writing software is available on the Web
sites of the software manufacturers and
software distributors. (Accessible from the
links in each software application)
