Champion Series
9/2003 3 TP 300-3883-02-CH-SN
Quick Setup List -
Page Setup Procedure Steps to Perform
4 Uncrating
❏ Remove crate & banding.
❏ Place transmissions in PUSH position & roll off skid.
4 Battery Activation &
❏ Charge the battery (Note: proceed with other setup steps
Installation while battery is charging).
❏ Test battery with hydrometer or load-tester.
❏ Install & secure battery.
5 Rider Assembly
❏ Install the seat and connect the seat switch
❏ Install ground speed control levers.
6 Check Fluid Levels
❏ Fill & check Engine oil level.
❏ Check transmission fluid level.
❏ Reduce & check tire pressures
(Front tires 40 psi, rear tires 15 psi).
7 Mower Assembly
❏ Torque mower blade bolts.
7 Lubrication
❏ Lubricate all grease & oil points.
8 SAFETY CHECKS
❏ Check for LOOSE HARDWARE.
❏ Check all OPERATOR CONTROLS.
❏ Test PARKING BRAKE.
❏ Perform MOWER BLADE STOPPING CHECK.
(Blade must stop within 5 seconds!)
❏ Perform SAFETY INTERLOCK SYSTEM CHECK.
9 Burnish Electric Clutch
❏ Burnish electric clutch (run for 15 seconds, repeat 10 times).
❏ Repeat MOWER BLADE STOPPING CHECK.
(Blade must stop within 5 seconds!)
