Smooth Fitness 7.35 R User Manual
Page 8
8
7.35 R TREADMILL
PARTS LIST
ITEM
Part Number
DESCRIPTION
Q'TY
735R-
101
F500314-001 Base
frame
1
735R-
102
F300013-000 Pad
2
735R-
103
F300450-000
Front mobile wheel cover
2
735R-
104
F300451-000 Front mobile
wheel
2
735R-
105
H020803-004 BoltM4x10
mm
4
735R-
106
H020208-000 BoltM4x12
mm
2
735R-
107
H048014-000 Air
shock
1
735R-
108
H020603-002 Bolt
M8x30
mm
2
735R-
109
H022302-000 Nut
M8
mm
3
735R-
110
F500317-000 Upper locking tube
1
735R-
111
F519053-000 Lower
locking tube
1
735R-
112
H020607-000 Bolt
M8x55
mm
1
735R-
113
H020606-000 Bolt
M8x50
mm
1
735R-
114
F500331-000 Lift
arm
1
735R-
115
H022144-001 Hex.
Screw
39mm
2
735R-
116
F060012-000 Washer,
stud
4
735R-
117
H020800-001 Bolt
M8x15
mm
4
735R-
118
H022101-001 Hex.
Screw
53mm
2
735R-
119
F991018-000 Incline
motor
1
735R-
120
H020300-002 Bolt
M10x45
mm
1
735R-
121
H020300-004 Bolt
M10x55
mm
1
735R-
122
H022303-000 Nut
M10
2
735R-
123
F373250-000 Motor
control
1
735R-
124
H020803-000 Bolt
M4x10
mm
4
735R-
125
F900464-000 Front
roller
1
735R-
126
F298004-000 Rear
roller
1
735R-
127
H020608-001 Bolt
M8x70
mm
3
735R-
128
H020603-005 Bolt
M8x30
mm
1
735R-
129
F500316-001 Running deck frame
1
735R-
130
F330002-000 Rubber
cushion
8
735R-
131
H020700-000 Bolt
M6x15
mm
10
735R-
132
F580014-000 Running deck
1
735R-
133
F570035-000 Running belt
1
735R-
134
F993014-000 Motor
1
735R-
135
H041002-000 Drive
belt
1
735R-
136
F300467-000 Lower
motor
cover
4
735R-
137
H020202-001 Bolt
M4x10
mm
2
735R-
138
F330001-000 Rear
wheel,
running deck frame
2
735R-
139
H020606-000 Bolt
M8x50
mm
2
735R-
140
F300449-000 Side
Rail
2
735R-
141
F300388-101 Right end cap
1
735R-
142
F300387-101
Left end cap
1
735R-
143
H020207-002 Bolt
M4x15
mm
4
735R-
144
F080006-002 Lower
console
wire
1
735R-
145
F083008-001 Power
cord
1
735R-
146
F376000-000 Electric
socket
1
735R-
147
H020200-001
Bolt M3x8 mm
2
735R-
148
F091001-000 ON-OFF
switch
1
735R-
149
F090004-000 Fuse
1
735R-
150
F270650-000 Mudguard, motor control
1
735R-
151
F270465-000 Mudguard, drive belt
1
735R-
152
F300489-000 Back
cover
1
735R-
153
H020803-000 Bolt
M4x10
mm
15
