COMMERCIAL COMPONENTS
Footnotes:
TP 400-5057-3-VA-N
Manual No.
7006174
PUSH YARD VACUUM
SERIES 0
11
Part No
Description
Item
Qty
Note
1
1
* ENGINE, 5.5HP Honda GXV, Recoil Start
Model GXV160K1N1AH
(Custom)
2
7075940
1
CABLE, Throttle, Honda
3
7090238
3
SCREW, 5/16-24 x 1” Hex Head Cap
4
7090700
1
BOLT, 5/16-18 x 1-1/2” Hex Flange Lock
5
7090585
1
NUT, 5/16-18 Hex Flange Lock
6
7075890
1
LINER, Vacuum Housing L.H.
7
7075889
1
LINER, Vacuum Housing R.H.
8
7092103
12
SCREW, 1/4-20 x 3/4” Flat Head Machine
9
7091294
12
WASHER, .28 x .63 x .06 Flat
10
7027223
12
WASHER, .263 Split Lock
11
7091576
12
NUT, 1/4-20 Hex
12
7075954
1
FRAME, Inlet Protection
13
7092106
5
SCREW, #10 x 3/4” Hex Washer
14
7044891
1
WELDMENT, Upper Housing, Commercial
15
7044932
1
WELDMENT, Impeller, Honda Commercial
16
7010783
2
KEY, #55 Hi-Pro
17
7077680
1
SETSCREW, 1/4-20 x 3/8”, Socket Head Knurled Cup Point
18
7012271
2
WASHER, Shim
NOTE: * Purchase engine & engine parts other than those listed, from engine service outlets.
