38
Chapter 2 Setting/Displaying Time Data and Text Information
Chapter 2
Setting/Displaying Time Data and Text Information
Displaying Time Data and Unit’s Operating Status
−Superimposing Text
Information
2 Time code reader drop-frame mark (for DSR-2000A only)
3 Time code generator drop-frame mark
(for DSR-2000A only)
4 VITC field
“ ” (blank): Fields 1 and 3
“*”: Fields 2 and 4
5 Recorder/player selection
The indication changes depending on the status of the RECORDER/
PLAYER buttons.
No display: Neither of the RECORDER and PLAYER buttons is lit.
P: The PLAYER button is lit.
R: The RECORDER button is lit.
6 Operation mode
The field is divided into three blocks, A, B and C.
• Block A displays the operation mode.
• Block B displays the servo lock status or tape speed.
• Block C displays a
p mark to indicate an edit section during automatic
editing.
A B C
. Drop frame mode (factory default setting)
: Non-drop frame mode
. Drop frame mode (factory default setting)
: Non-drop frame mode
