18
KS-342
Other parameters
Microphone power P-48V (maximum power 10 mA)
A-B 12V (maximum power 30 mA)
LCF (low-cut filter) 20 Hz — 200 Hz, continuously variable, –12 dB/
octave
Oscillator 1 kHz (±10%)
Compressor Threshold level +3/+6/+9/+12 dB
Attack time 2 ms (approx)
Release time 300 ms (approx)
Ratio 2:1 (approx)
Audio performance
Frequency response MAIN OUT
&
SUB OUT 30 Hz — 40 kHz (within 1 dB)
Noise level MIC (–70) < –54 dB (22 kHz LPF/RMS)
LINE
(+4) < –70 dB (22 kHz LPF/RMS)
MONI < –65 dB (22 kHz LPF/RMS)
Total Harmonic Distortion (THD) <0.1% (50 Hz — 15 kHz
+4 dBm)
