Specifications shown are for SP mode unless specified otherwise.
E. & O.E. Design and specifications subject to change without
notice.
Specifications
GENERAL
Power : 110 V – 240 V d , 50 Hz/60 Hz
Power consumption
Power on : Approx. 12 W
Standby mode : 3.0 W
Video Head system
HR-J695EA : DA4 (Double Azimuth) head helical
scan system
HR-J291EA : Rotary two-head helical scan system
Tape speed
(SP) : 23.39 mm/sec
(LP) : 11.69 mm/sec
Tape format : Tape width 1/2"
(12.7 mm high density VHS tape)
Maximum recording time
(SP) : 240 min. with E-240 video cassette
(LP) : 480 min. with E-240 video cassette
Rewind time : Approx. 180 (±30) sec. with E-180
cassette
Dimensions (W x H x D) : 360 mm x 94.5 mm x 270 mm
Weight
: 4.0 kg
Operating temperature : 5°C to 35°C
Operating humidity : Less than 80 %
Timer : 24 hours display type
VIDEO
Signal system : PAL-type colour signal and CCIR
monochrome signal, 625 lines
50 fields
Recording Format : PAL/MESECAM/NTSC 3.58/
NTSC 4.43
RF reception
HR-J695EA : PAL B/G, SECAM D/K
HR-J291EA : PAL B/G
RF OUT : PAL B/G
RF modulator : UHF channels 22 – 68 (Adjustable)
Input level : VIDEO IN (RCA type)
1.0 Vp-p, 75 Ω, unbalanced
Output level : VIDEO OUT (RCA type)
1.0 Vp-p, 75 Ω, unbalanced
Signal-to-noise ratio : More than 43 dBm
AUDIO
Input level : AUDIO IN (RCA type)
–6.0 dBm, more than 47 k Ω
Output level : AUDIO OUT (RCA type)
–6.0 dBm, less than 1 k Ω
Audio track
HR-J695EA : Mono track and Hi-Fi track
HR-J291EA : Mono track
Audio frequency response
Normal audio : 100 Hz to 10,000 Hz
(–6/+3 dBm)
Hi-Fi audio* : 20 Hz to 20,000 Hz
(–3/+3 dBm)
* HR-J695EA only
Audio signal to noise ratio
Normal audio : More than 43 dB (JIS A filter)
Hi-Fi audio* : More than 70 dB (JIS A filter)
* HR-J695EA only
Audio dynamic range [HR-J695EA only]
Hi-Fi audio : More than 85 dB (JIS A filter)
ACCESSORIES
Provided accessories : RF cable,
Infrared remote control unit,
“R3” battery x 2
