Remote Control
FUCTION
P1 P2 P3
P4 SLEEP
TREBLE TREBLE
SET ST/MO
1 2
3 4
5
6 7
8
9 10
11
12
13
14
15 16
17
18
LOCATION OF CONTROLS
E7
SNOOZE/DIMMER
1) POWER On/ Standby button.
2) Mute Speakers button.
3/4) / TREBLE level Up/Down button.
5/11) / Volume Up/Down button;Clock hour/minute adjustment.
6/7) / Radio Tune up/down; iPod skip/search forward / backward
button. for Backward, for Forward;Clock hour/minute setting
selection.
8) button: iPod Play/Pause.
9) button: Set the clock and alarm time; alarm/wake to alarm mode
selection.
10) button: FM Stereo/Mono selection.
12)13)14)17) button: Save the FM radio preset stations.
15) button: Select Function mode.
16) button: Sleep timer
18) button: Snooze/Dimmer
TREBLE TREBLE
SET
ST/MO
P1 P2 P3 P4
SLEEP
FUNCTION
SNOOZE/DIMMER
LCD Display
PM
AUX
iPod Mode FM radio mode AUX mode
PM
iPod
VOLUME
RADIO
MHz
Clock / Standby mode
(Back light is off) Alarm clock mode
PM PM
FM
VOLUME VOLUME
