– 1 –

LCD Projector Compatible with Installation

Model Name: LX-D1000 (Body’s mass is 4.5 Kg)

For Selling and Installing Stores

Read this instruction manual carefully before assembly and/or installation. Be sure to carry out the
work properly always with safety in mind.

Do not permit the customers to engaged in assembly and/or installation. Make sure that your custom-
ers request you, the professional installers, for assembly and/or installation.

It is mandatory that you use the provided accessories for assembly and/or installation work. The metal
fixtures cannot be used for the LCD (liquid crystal display) projectors and appliances other than those
that are designated by our company.

The total mass of the metal mixtures for the ceiling is 5.5 Kg.

DETAILS TO BE STRICTLY OBSERVED FOR SAFETY

Before assembly and/or installation, be sure to read carefully the “details to be strictly observed for safety.”
The risk and its extent caused by erroneous handling are demarcated as follows:

WARNING

Probability that can result in critical consequences such as death or serious injury in case of erroneous
handling.

CAUTION

Probability that can result in injury or damage of houses and/or household effects in case of erroneous han-
dling.

Carry out installation so that a safety rate definitely comes to
more than 5 times.

Select a strong place where the mass of the LCD projector and
the metal fixtures can be held sufficiently.
If they are installed at a spot having insufficient strength, the
metal fixtures attached to the ceiling can come off and fall, re-
sulting in injury.

WARNING

Be sure to carry out installation under a ceiling with a horizontal
surface.

Avoid installation under an inclined or warped ceiling.

CAUTION

Take necessary measures to prevent any possible swing using
wires, etc.

Otherwise, temblors and vibrations can result in falls, causing
injury.

Be sure to install them at a place where there is no other appa-
ratus such as a fire alarm, etc., or malfunction of appliances and
instruments, etc., can result.

Pay attention not to allow any children hang onto the fixtures.

Otherwise, injury can result.

INSTRUCTION MANUAL

FOR ASSEMBLY AND INSTALLATION OF

EF-L1000CG

BHU30002-036-001
