Page 22
21
VIDEO Setting
g
“Setting video terminals” (P. 22)
HDMI-1 Audio
Setting
Set to “Digital” or “Auto” for HDMI devices,
or “Analog” or “Auto” for DVI devices. (Not
available for HDMI-2 and HDMI-3.)
HDMI Mode Setting
For setting the HDMI input
If there is no picture displayed on the
screen, set “Mode” to “1” or “2”.
PC Setting
For setting the PC input
PC Position:
Adjust screen position
Phase:
Sets the focus of the screen.
Pixel:
Adjusts the horizontal feature of the screen.
Set Up
Set Up
Video Setting
HDMI-1 Audio Setting
HDMI Mode Setting
PC Setting
Auto
z
“PC Setting” is only available when
“AV Select” is set to “PC”. (P. 13)
Note
HDMI- 1
2
Mode
Mode
HDMI Mode Setting
HDMI- 2
2
Mode
HDMI- 3
1
Phase
Pixel
PC Setting
PC Position
Ⅵ
Adjust the position of the PC image
z
Reset position
g
A
adjust
B
set
A
select “PC Position”
B
enter
PC Position
(blue)
