Specifications
General
Readable discs:
DVD AUDIO, DVD VIDEO, Audio CD, Video CD
Video format:
NTSC, 525i/525p selectable
Other
Power requirements:
AC 120 V
, 60 Hz
Power consumption:
15 W (POWER ON), 2.5 W (STANDBY mode)
Mass:
2.6 kg (5.8 lbs)
Dimensions (W x H x D):
435 mm x 73 mm x 267.5 mm
(17-3/16 inch x 2-7/8 inch x 10-9/16 inch)
Video outputs
COMPONENT (pin jacks):
Y Output:
1.0 Vp-p (75
Ω)
P
B
/P
R
Output:
0.7 Vp-p (75
Ω)
VIDEO OUT (pin jack):
1.0 Vp-p (75
Ω)
S-VIDEO OUT (S jack):
Y Output:
1.0 Vp-p (75
Ω)
C Output:
286 mVp-p (75
Ω)
Horizontal resolution:
500 Lines or more
Audio outputs
ANALOG OUT (pin jack):
2.0 Vrms (10 k
Ω)
DIGITAL OUT: (COAXIAL):
0.5 Vp-p (75
Ω termination)
(OPTICAL):
–21 dBm to –15 dBm (Peak)
Audio characteristics
Frequency response:
CD
(sampling frequency 44.1 kHz):
2 Hz to 20 kHz
DVD
(sampling frequency 48 kHz):
2 Hz to 22 kHz
(2 Hz to 20 kHz for DTS and Dolby Digital bitstream signals)
DVD
(sampling frequency 96/88.2 kHz):
2 Hz to 44 kHz
DVD
(sampling frequency 192/176.4 kHz): 2 Hz to 88 kHz
Dynamic range:
16 bit: More than 98 dB
20 bit: More than 110 dB
24 bit: More than 110 dB
Wow and flutter:
Unmeasurable (less than ± 0.002%)
Total harmonic distortion:
less than 0.002%
* Specifications and appearance subject to change without prior notice.
