Additional information
Names of parts and controls
Front panel
1 button (10)
2 STANDBY/ON indicator (10)
3 Disc tray (11)
4
0 button (11)
5 4 button (14, 15)
6 ¢ button (14, 15)
7 7 button (12, 13)
8 3 button (11, 13)
9 8 button (12, 14)
0 Display window (see the illustration below)
- Remote sensor (8)
= PROGRESSIVE indicator (5)
~ DVD AUDIO indicator (2)
Display window
1 Audio format indicators
2 Disc indicator
3 Group/title/track/chapter indicators
4 Repeat mode indicator
5 Program/random indicators 6 Total time/remaining time indicators
7 kHz (unit of sampling frequency) indicator
8
3(play) / 8(pause) indicators
9 Multi-information window
= 0 - ~
1 2 3 4 5 9 8 7 6
2 1 4 7 5 6 3
8 9
