Specifications
CDR section
System: Compact disc digital audio recording system
Sampling frequency: 44.1 kHz
Signal-to-noise ratio: 90 dB
Dynamic range: 90 dB
Frequency response: 20 Hz to 20 kHz
Wow and flutter: Less than measurable limit
Total harmonic distortion: 0.01%
Input:
ANALOG IN: Minimum input level: 300 mV
(Full scale –12 dB)/47 k
Ω
OPTICAL IN: Input level: –23 dBm to –15 dBm
(with sampling rate 32 kHz, 44.1 kHz, 48 kHz)
Output:
ANALOG OUT: 2V/50 k Ω ( Full scale)
(Full scale –12 dB)/50 k
Ω
OPTICAL OUT: Output level: –21 dBm to –15 dBm
(with sampling rate 44.1 kHz)
COAXIAL OUT: 0.5 Vp-p/75
Ω
General
Power requirement: AC 120 V , 60 Hz
Power consumption: 20 W
Dimensions (approx.): 270 mm x 95 mm x 353 mm (W/H/D)
(10
11 / 16 in. x 3 3 / 4 in. x 13 15 / 16 in.)
Mass (approx.): 3.8 kg (8.4 lbs)
Supplied accessories
See page 5.
Design and specifications are subject to change without notice.
