Specifications:
Enclosure Type:
Sealed
Driver Type: 10W3v3-4
Nominal Impedance: 4

Cont. Power Handling: 300Watts

JL Audio recommends using a high quality amplifier such as the JL Audio 250/1. The diagram below shows the recommended
crossover, infrasonic filter and equalizer settings for the 250/1 when being used to power your Stealthbox®.

Included Hardware:
(1)
Wax Square
(1) 2-14”Socket Cup Set Screw
(1) Fender Washer
(1) Flat Washer
(1) Lock Washer
(1) Hex Nut

10369 N. Commerce Pkwy, Miramar, Florida 33025-392 Phone: 954.443.1100 Fax: 954.443.1111

JL AUDIO 250/1

monoblock subwoofer amplifier

Amplifier Input Section

Input Sens.

Input Voltage

Low/High

Left Ch.

Right Ch.

Signal Sensing

Off/On

Output Mode

Full-Range/Low-Pass/High-Pass

Left Ch.

Right Ch.

Amp LP Filter

Mode/Slope

Off/12dB/24dB

Filter Freq. (Hz)

Bass Control

LF Boost (dB)

Off/30Hz

Infrasonic Filter

+1

+13

+3

+7

+10

Preamp Output Section

+12VDC

Ground

Remote

The JL Audio 250/1 is a very versatile audio component. Please consult the owner’s manual for detailed information
about installing and tuning this amplifier.

STEP 11: With the shoulder belt through the bot-
tom crease. Snap the belt back into the latch.

STEP 12: Flip the rear seat back into the up-right
position.

S B - G M - C L D RO / 1 0 W 3 v 3 , J L AU D I O, I n c 2 0 0 6

S h e e t S K U # 0 1 1 1 8 9 R ev i s i o n 3 / 8 / 2 0 0 6

Pa g e 3

w w w . j l a u d i o . c o m

Mid/High Frequency Driver Information:

CONGRATULATIONS!
INSTALL COMPLETE.

XR650-CSi

VR650-CXi

Front Location Driver Size:
6.5” separates

Applicable JL Audio Products:
VR, XR,VR & TR 650-CSi
*with 1/2” spacer

Rear Location Driver Size:
6.5”

Applicable JL Audio Products:
XR,VR & TR 650-CXi
*with 1.0” spacer

Cont.
From

Previous

Page

Difficulty Of Installation:
