2 | JL Audio - C2-570x Owner’s Manual
D
C
B
A
A
Due to ongoing product development, all specifications are subject to change without notice.
woofer Physical Dimensions
Frame outer Diameter (a) 5.47 x 7.68 in. / 139.0 x 195.0 mm
magnet outer Diameter (B) 2.76 in. / 70.0 mm w/o cover
Frontal Tweeter Protrusion (C) 0.47 in. / 11.9 mm
mounting Depth (D) 2.43 in. / 61.9 mm w/o cover
