10 | JL Audio - C3-570 Owner’s Manual
Connectthespeakerwirestobothsetsof
terminalsoneachspeaker,observingcorrect
polarityandmakingsurethatthetweeterand
wooferwirescorrespondtothecorrectterminals
onboththespeakerandthecrossover.
Securethespeakerandspacergasket(if
applicable)tothepanelbyevenlytightening
byhandmountingscrews.Usethesupplied
mountingclipsandthetheprovided#8x1.25
inch(32mm)mountingscrewsunlessthe
factoryholesalreadyfeaturethreadedinserts.
Custom location:Runspeakerwiretothe
desiredmountinglocations.Ifyouarerunning
wiresintoadoor,useexistingfactorywiringboots
wheneverpossible.Ifyouaredrillingnewholes,file
theiredgesandinstallrubbergrommetsintoeach
hole.Wiresshouldthenbecoveredwithaprotective,
flexiblePVCsleeveandthenrunthroughthedoor
jamb.Makesurethatthewireswillcleardoorhinges
andotherstructuresinthedoor.Ifyouareunsure
aboutanypartofthisprocess,pleasecontactyour
JLAudiodealerforinstallationhelp.
Selectanevensurface.Tighteningaspeakeronto
anunevensurfacecandamageit.Usethesupplied
templatetomarkthedesiredmountinglocation.
Markthecenterandtheoutlineofthemounting
holeaswellasthemountingscrewpositions.
Beforedrillingorcuttingonyourinteriorpanels,
useautilityknifetocutanyfabric,vinylorleather
fromholelocations.Thesematerialscaneasily
besnaggedbyadrillorasaw,causingdamageto
thepanelandpossiblebodilyinjury.Drillfour
1/8-inch(3mm)holesforthespeaker’smounting
screwsatthepositionsyouhavemarked.Alsodrill
apilotholeinthecenterofthespeakermounting
holeatthistime.Then,usingasabersaw,make
thecircularcutoutforthespeaker.Fileanyrough
edges.Insertthemountingclipswiththeflatside
towardsthespeakerasshowninDiagramI.
Itisabsolutelyvitalthatthespeakerframe
fitsintothemountingholecleanly.Thismustbe
WARNING
!!
Double check the clearance for both speakers
before proceeding. Many cars are different from
one side to the other!
wooFer InsTallaTIon
Thewoofersshouldbeinstalledinoneofthe
followingwaysdependingonlocation:
Factory location:Ifyouwillbeusingthefactory
speakerwires,itmaybenecessarytochangethe
terminations.Thismaybeaccomplishedbyusing
anadaptorplugorsimplybycuttingthefactory
connectoroffandusingthesuppliedcrimp
connectorstoterminatethespeakerwires.The
largeconnectorisforthepositive(+)terminaland
thesmallconnectorisforthenegative(–)terminal
ofeachwoofer.Keepinmindthatthewooferwires
mustbeconnectedtothewooferoutputsofthe
crossoverssuppliedwithyoursystemasshowninthe
diagramonpage5.Ifyouprefertorunnewwires,
refertothe“CustomLocation”installationsection
fordetails.Whichevermethodyouchoose,observe
correctpolarityinyourconnections.Ifyouare
unsureaboutanyoftheseissues,contactyour
JLAudiodealerforinstallationassistance.
Yournewspeakershavebeendesigned
toinstall,withoutmodifications,intomost
vehiclesthataccepta5x7-inch(125x180mm)
speaker.Mostfactory5x7-inchspeakersuse
fourmountingscrewswhichwilllineupwith
themountingholesonyourspeakers.
Aspacergaskethasbeenincludedtofine-tune
speakerfitment.Thisgasketcanbemountedonthe
frontofthemountingflange,thebackofthemounting
flangeorsimplynotbeusedintheinstallation.
Itisabsolutelyvitalthatthespeakerframe
fitsintothemountingholecleanly.Thismustbe
checkedpriortotighteningthescrews.Donot
forcetheframeintoaholethatistoosmall.Do
nottightenthespeakerontoanunevensurface.
Thiswilldamageyourspeakers.Thespeaker
shouldalsofitsothatairdoesnotleakaround
themountingflange.Airleakswillcauseasevere
degradationinsoundquality.Sealanyairleaks
withanautomotive-gradesealantmaterial.
