CV-A50 / CV-A60
7.2. CV-A50/60 RS-232C command list.
Command Name Format Parameter Remarks
A – General settings and useful commands
EB Echo Back
EB=[Param.] 0=Echo off 1=Echo on Off at power up
ST Camera Status request ST? Actual setting
HP Online Help request HP? Command list
VN Firmware version VN? 3 letter version
B – Timing and shutter related commands
SC Scanning format
SC=[Param.] 0=Interlaced
2=1/2 partial
1=Non-interl.
3=1/3 partial
Partial scanning is
not supported
TR Trigger mode TR=[Param.] 0=normal
2=Pulse width
4=Long time
1=Edge
3=Frame delay
5=Start/stop
SM Shutter mode SM=[Param.] 0=Normal 1=Programmab.
SH Shutter speed SH=[Param.] 0=Off
0=1/50 (1/60)
2=1/250
4=1/1000
6=1/4000
1=1/100
1=1/125
3=1/500
5=1/2000
7=1/10000
Continuous only
Trigger modes and
Continuous
PE Programmable expos. PE=[Param.] 0= No function
1023=1023.5H
1=1.5H CCIR. H=64µsec
EIA, H=63.5µsec
*1)
C – Signals and polarity
FR Accumulation
FR=[Param.] 0=Field 1=Frame
PC Pixel clock PC=[Param.] 0=no clock out 1=clock out Should be off
when not used
TP Trigger polarity TP=[Param.] 0= active low 1= active high *2)
WP WEN polarity WP=[Param.] 0= active low 1= active high
D – Gain and analogue signals setting
AS AGC Switch
AS=[Param.] 0=AGC off 1=AGC on 0= manual gain
AG AGC Level AG=[Param.] 0=low 255=high Range 0 to 255
GA Manual gain Level GA=[Param.] 0=low 255=high Range 0 to 255
RP Rear Potentiometer RP=[Param.] 0=manual gain 1=rear potm.
SU Setup Level SU=[Param.] 0=low 255=high Range 0 to 255
WC White clip Level WC=[Param.] 0=low 255=high Range 0 to 255
GS Gamma Select GS=[Param.] 0=gamma 1 1=gamma 0.45
E – Saving and loading data in EEPROM
LD Load settings from
camera EEPROM
LD=[Param.] 0=Factory data
2=User 2 area
1=User 1 area
3=User 3 area Latest used data
area becomes
default at next
power up
SA Save settings to
camera EEPROM
SA=[Param.] 1=User 1 area
3=User 3 area
2=User 2 area
*1)
In normal non trigger mode (TR=0) PE<312 for CCIR and PE<262 for EIA. In trigger mode TR=1, EEN will not be correct if
PE>833.
*2) If positive logic is used (TP=1), the first trigger pulse after power up will be ignored.
!! Do not try to use commands not shown in the list.
