LOCATION OF THE BUTTONS
u RND (random) button
i Number buttons
o E (EQ: equalizer) button
; CD button
a
∞ (down) button
–10 button
Display window
s LOUD indicator
d EQ (equalizer) indicator
f CD–in indicator
g CD indicator
h FM band indicators (FM1, FM2, FM3)
j AM band indicator
k Tuner reception indicators
MO (monaural), ST (stereo)
l RND (disc random) indicator
/ Volume (or audio) level indicator
z Main display
x RPT (repeat) indicator
Control panel
1 Remote sensor
2 Control dial
3
(standby/on/attenuator) button
4 SEL (select) button
5 Screws—M2
× 5 mm (1/4") (only for KD-SC800)
6 Plate cover and standard plate
(only for KD-SC800)
7 FM/AM button
8
5 (up) button
+10 button
9 0 (eject) button
p 4 / ¢ buttons
q (control panel release) button
w DISP (display) button
• Also functions as SSM buttons when pressed
together with M (MODE) button.
e M (MODE) button
• Also functions as SSM buttons when pressed
together with DISP (display) button.
r Display window
t MO (monaural) button
y RPT (repeat) button
Display window
