EN
9 GETTING STARTED
MasterPage: Start_Right
GETTING ST
AR
TED
Controls
1 Rewind Button [ 1 ] ( ੬ pg. 21)
Left Button [ 1 ]
Quick Review Button [QUICK REVIEW]
(
੬ pg. 21)
2 Set Button [SET] ( ੬ pg. 16)
Data Battery Button [DATA] ( ੬ pg. 14)
3 Stop Button [ 7 ] ( ੬ pg. 21)
Down Button [ 4 ]
Backlight Compensation
Button [BACKLIGHT]
4 VIDEO/MEMORY Switch ( ੬ pg. 15)
5 Play/Pause Button [ 6 ] ( ੬ pg. 21)
Up Button [ 3 ]
Manual Focus Button [FOCUS] ( ੬ pg. 37)
6Wide (16:9) Button [16.9] ( ੬ pg. 36)
Blank Search [BLANK] ( ੬ pg. 22)
7Menu Button [MENU] ( ੬ pg. 31)
8Fast-Forward Button [ ¡] (੬ pg. 21)
Right Button [2]
Night Button [NIGHT] (
੬ pg. 37)
9Index Button [INDEX] ( ੬ pg. 27)
LED Light Button [LIGHT]
!Diopter Adjustment Control ( ੬ pg. 17)
"Auto Button [AUTO] ( ੬ pg. 15)
#Snapshot Button [SNAPSHOT]
( ੬ pg. 26, 37)
Live Slow Button ( ੬ pg. 31, 36)
$Power Zoom Lever [T/W] ( ੬ pg. 20)
Speaker Volume Control [VOL. +, –]
(
੬ pg. 21)
%Battery Release Button [PUSH BATT.]
( ੬ pg. 13)
&Recording Start/Stop Button ( ੬ pg. 19)
(Power Switch [REC, PLAY, OFF] ( ੬ pg. 15)
)Lock Button ( ੬ pg. 15)
~Cassette Open/Eject Switch [OPEN/EJECT]
( ੬ pg. 18)
Connectors
The connectors are located beneath the covers.
+USB (Universal Serial Bus) Connector
( ੬ pg. 44)
,Digital Video Connector [DV IN/OUT] (i.LINK*)
( ੬ pg. 43, 44)
* i.LINK refers to the IEEE1394-1995 industry
specification and extensions thereof. The
logo is used for products compliant with the
i.LINK standard.
-Audio/Video Output Connector [AV]
( ੬ pg. 23, 42)
.DC Input Connector [DC] ( ੬ pg. 13)
Indicators
çPOWER/CHARGE Lamp (੬ pg. 13, 19)
Other Parts
éLCD Monitor (੬ pg. 19, 20)
èViewfinder (੬ pg. 17)
êCard Cover [ ] ( ੬ pg. 18)
ëBattery Pack Mount (੬ pg. 13)
íShoulder Strap Eyelet (੬ pg. 12)
ìGrip Strap (੬ pg. 17)
îSpeaker (੬ pg. 21)
ïLens
ñLED Light
óCamera Sensor
(Be careful not to cover this area, a sensor
necessary for shooting is built-in here.)
òStereo Microphone
ôStud Hole (੬ pg. 17)
öTripod Mounting Socket (੬ pg. 17)
õCassette Holder Cover (੬ pg. 18)
úMemory Card Slot
