Names of parts and controls
Front panel
1 STANDBY indicator (8)
2
STANDBY/ON button (8)
3 Disc trays (1 - 5) (9)
4
0 buttons (1 - 5) (9)
5 Disc buttons (1 - 5) (10)
6 Disc indicators (1 - 5) (10)
7 MIC 1/2 jacks (26)
8 MIC 1/2 level controls (26)
9 Remote sensor (6)
0 PROGRESSIVE indicator (4)
- Display window (see the illustration below)
=
4 button (12, 13)
~ ¢ button (12, 13)
! 7 button (10, 11)
@ 3 button (10, 12)
# 8 button (11, 12)
Display window
1 Audio format indicators
2 Disc indicator
3 Karaoke indicator
4 Group/title/track/chapter indicators
5 Repeat mode indicator
6 Program/random indicators 7 Total time/remaining time indicators
8 3D (3D PHONIC) indicator
9
3(play) / 8(pause) indicators
0 Resume indicator
- Multi-information window
9 7 0 - = ~ ! @ #
1 2 3 4 5 6
8
2 3 1 5 6 7 4
9 8 0 -
