16
Superimpose
This function, switchable between ON and OFF, determines
whether or not operational indicators will appear on screen.
ACCESS MAIN MENU
SCREEN
1
Press MENU.
ACCESS FUNCTION SET
SCREEN
2
Place the arrow next to "FUNCTION SET" by
pressing CH
5∞, then press OK.
ACCESS SUPERIMPOSE
SCREEN
3
Place the arrow next to
"SUPERIMPOSE" by
pressing CH
5∞, then
press OK.
SELECT MODE
4
Place the arrow next to
"ON" or "OFF" by pressing
CH
5∞.
RETURN TO NORMAL
SCREEN
5
Press MENU as many times as necessary.
q
2 3
6 5 / 8
MENU
SUPERIMPOSE
=ON
OFF
PRESS ( 5,∞) TO SELECT
PRESS (MENU) TO END
FUNCTION
AUTO TIMER
=SUPERIMPOSE
PRESS ( 5,∞), THEN (OK)
PRESS (MENU) TO END
CH
"Cassette Loaded" mark
When a cassette is loaded, the mark is
displayed for 5 seconds. It blinks when the
VCR's EJECT button is pushed.
CH 125 RECORD
THU 12:00 AM PAUSE
] SP
INDEX-1
COUNT –1:23:45
Tuned-in channel or AUX(iliary) mode
When the channel is changed, the new
channel is displayed on the screen for 5
seconds.
Clock time
Tape position indicator
Tape speed indicator
INDEX indication
Counter reading
Operation mode
When the operation mode is changed,
the new mode is displayed — RECORD
(5 sec.), PLAY (5 sec.), FF/REW (5 sec.
when engaged from Stop mode),
RECORD PAUSE (for as long as Pause is
engaged), and ITR *:** (5 sec.).
The superimposed indication on the TV screen tells you what the VCR is doing.
To recall an indication
1 Press OSD.
Ⅲ All indications corresponding to the current status are
displayed for 5 seconds, leaving the counter information,
and RECORD/PAUSE if in the Record Pause mode, on
the screen. (No indication during still and search.)
2 Press OSD again to clear the display.
7 8
0
9
q 6 5
4
Y T
2 3
OK
MENU CH
OSD
B E + + +
OK
PLAYBACK AND RECORDING FEATURES (cont.)
