FireStore DR-DV5000 QuickStart Guide
PAGE 8
MANL-0899-02
DR-DV5000 RECORD AND CONTROL LCD AND CAMCORDER VIEWFIDER
DISPLAY MODES
When used with a JVC GY-DV5000 series camcorder, it is possible to monitor DR-DV5000 status
in the camcorder’s viewfinder (EVF) and on the LCD display. When DR-DV5000 is connected to
a GY-DV5000 and powered, a small “DD” icon will appear in the top right side of the camcorder
EVF and LCD. Next to this will be four characters which will appear like “092S”. The three
numerical values (092) represent the remaining disk space on the FireWire disk drive (in this case
92 minutes). The letter displays the DR-DV5000 Record/Playback and Control Mode (S - in this
case STOP). The different display modes are listed below:
PLAY/REC MODE
CAM EVF/LCD*
DR-DV5000 LCD
TALLY
Stop
S
STOP
Off
Pause
P blink
ll PLAY
Off
Play
> PLAY
Off
Normal
Rec (Pause)
R blink
ll REC
Blink
Normal Rec (Rec)
R
REC
On
Retro Disk (Stop)
S
L STOP
Off
Retro Disk (Standby)
L blink
L REC
Blink
Retro Cache (Stop)
S
C STOP
Off
Retro Cache (Standby)
C blink
C REC
Blink
Loop Record (Stop)
S
O STOP
Off
Loop Record (Standby
O Blink
O REC
Blink
Loop Record (Rec)
O
O REC
On
Time Lapse (Stop)
S
T STOP
Off
Time Lapse (Pause)
T blink
ll T REC
Blink
Time Lapse (Rec)
T
T REC
On
Snap (Stop)
S
SNAP
Off
Snap (Standby)
G
ll SNAP
Off
Snap (Rec)
G
SNAP
On
CONTROL TYPE
CAM EVF/LCD*
DR-DV5000 LCD
TALLY
Series Rec** (Stop)
D
D
Off
Series Rec** (Pause)
D
D ll
Blink
Series Rec (Rec)
D
D
On
AV/C* (Stop)
A
A
Off
AV/C* (Rec Pause)
A
A ll
Blink
AV/C* (Rec)
A
A
On
AV/C* (Play Pause)
A
A ll PLAY
Off
AV/C* (Play)
A
A PLAY
Off
Syncro Slave (Stop)
Y
Y
Off
Syncro Slave (Pause)
Y
Y ll
Blink
Syncro Slave (Rec)
Y
Y
On
Split Slave** (Pause)
Y
Y ll
Off
Split Slave** (Rec)
Y
Y
On
* AV/C is only for use when DR-DV5000 is connected to a computer system. To control
DR-DV5000 from a camcorder, use Syncro Slave or Split Slave Mode.
** Series Rec and Split Slave are only available when DR-DV5000 is used with a
JVC GY-DV5000 camcorder.
