7
iPod ADAPTORS
Please see below for the iPod Adaptor included in the package:
iPod Adaptor iPod Models
Docking Cover
iPod nano
iPod mini
3Gen iPod 10/15GB
4Gen iPod 20GB
iPod Photo 20/30GB
3Gen iPod 30/40GB
4Gen iPod 40GB
iPod Photo 40/60GB
Align 1st Gen iPod nano here
Align 2nd Gen iPod nano here
NOTE: No adaptors are provided for iPod with video 30GB, 60GB and 80GB. Please use the adaptors
included with these iPods at time of purchase. They will fit properly into the docking stations of
this system.
8
SYSTEM CONNECTION
Before using this speaker system, please following these steps to help you to set up the system.
1. Plug the AC adaptor into a standard wall outlet rated at 120V AC/60Hz.
2. Connect the output of the AC adaptor to the Power In jack on the back of the main unit.
3. Connect the docking station audio-cable plug to the AUX IN jack on the back of the main unit.
SYSTEM PLACEMENT
We recommend that you place the JiSS-550 properly on your desk, counter or table.
The
unit produces exceptional sound from any listening position in the room.
However , the best quality sound and surround sound effects will be heard with the unit
placed directly in front of you and facing you.
1-6ft
Preferred Not Preferred
Preferred Not Preferred
PC
USER
PC
USER
PC
USER
PC
USER
iPod
iPod
Docking
Station
Audio Cable
Audio Stereo
plug
AC out power
plug
120V AC/60Hz
W A L L O U T L E T
A C /A C
A da ptor
R efer to your iP od operation manual to adjust the “E Q” setting on your iP od. T his will enhance the sound
and also help adjust the sound to the room you are using it in.
1-6ft
