Jasco 45245 - Manual (Page 7)

7
Wireless Camera Systems - 45234, 45236, 45239,
45246. Each system can accept a maximum of two
cameras.
CAMERA CHANNEL SELECTION
Each wireless camera must be assigned to a specific
channel (1 or 2) through the use of a slide switch
located on the inside of the camera housing.
First slide off the sun shield and then unscrew the lens
from the camera. The receiver or monitor must
have its channel selection set to the same
corresponding number.
In a two camera system, one camera is set to
Channel 1 and the other is set to Channel 2.
The receiver or monitor must be set to the 2 camera
position in order to view both cameras alternately
(see receiver or monitor manuals for specific channel
selection requirements).
Channel
Selection
switch
2
1
