2 | JL Audio - C2-600x Owner’s Manual
A F
B
G
E
C
D
Due to ongoing product development, all specifications are subject to change without notice.
woofer Physical Dimensions
Frame outer Diameter (a) 6.21 in. / 157.7 mm
Grille Tray outer Diameter (B) 6.51 in. / 165.3 mm
magnet outer Diameter (C) 3.15 in. / 80.0 mm w/o cover
Frontal Tweeter Protrusion (D) 0.55 in. / 13.9 mm
Frontal Grille Protrusion (e) 0.91 in. / 23 mm
mounting Hole Diameter (F) 5.00 in. / 127.0 mm
mounting Depth (G) 2.38 in. / 60.3 mm w/o cover
