2 | JL Audio - C2-650x Owner’s Manual
A F
B
G
E
C
D
Due to ongoing product development, all specifications are subject to change without notice.
woofer Physical Dimensions
Frame outer Diameter (a) 6.50 in. / 165.0 mm
Grille Tray outer Diameter (B) 6.84 in. / 173.7 mm
magnet outer Diameter (C) 3.15 in. / 80.0 mm w/o cover
Frontal Tweeter Protrusion (D) 0.45 in. / 11.6 mm
Frontal Grille Protrusion (e) 0.85 in. / 21.6 mm
mounting Hole Diameter (F) 5.56 in. / 141.3 mm
mounting Depth (G) 2.44 in. / 61.9 mm w/o cover
