7
XL-MC334BK
LVT0022-001B [J]
BASIC OPERATION
Turning the power on
Check that the STANDBY indicator on the front panel is lit. Then
press the POWER button either on the front panel or remote control.
3. Place the disc in a slot, with its label facing to the left.
POWER
STANDBY
PLAY/PAUSE STOP/CLEAR
REPEAT PLAY MODE CALL
DISC/TRACK
EXCHANGE RANDOM INTRO
ENTER CANCEL
TRACK
OPEN/CLOSE
DISC
DOWN
DISC EJECT
ENHANCED COMPULINK CONTROL SYSTEM CD Label
DISPLAY CHARACTER TITLE INPUT DISC SERCH USER FILE
CAUTION
• Do not put anything except CDs in the storage area.
• Be careful not to touch the playback mechanism in the
unit.
• Up to 25 discs can be accessed at one time. Trying to
insert or remove a disc which is not in the loading area
may result in damage to the discs and unit.
• The disc needs to be placed vertically in the storage slot
of this component. After taking the disc out of its case,
grip the rim of the disc between your thumb and middle
finger — be sure to keep the fingers on the narrow, outer-
most strip where the surface is solidly bright.
• Do not try to put more than one disc in a single slot. The
unit will be damaged.
NOTE: 3-inch (8 cm) CDs cannot be played back in this unit.
4. Repeat step 3, or steps 2 and 3, to load discs in the storage. Up
to 200 discs can be loaded.
5. When all necessary discs have been loaded, press the OPEN/
CLOSE button to close the storage door.
The carousel rotates to bring the disc at the loaded/unloaded
position (in the center of the storage area) to the playback
position.
CAUTION
Make sure to remove your hand from the storage opening
before pressing the OPEN/CLOSE button.
Unloading/changing discs
1. Press the OPEN/CLOSE button to eject a disc in the playback
position for unloading or changing.
POWER
STANDBY
POWER
or
(Remote control)
To turn the power off, press the button again. The STANDBY
indicator will light.
NOTE: Keeping the unit in the standby state consumes a mini-
mal 6.0 watts. If necessary, unplug the power cord
from the AC outlet to turn off the power completely.
Please note, however, that the memorized data for
the user files and disc information will disappear in a
few days if the power is completely turned off.
Loading compact discs
Also see Page 22 for the manner of handling and taking care of
discs.
1. Press the OPEN/CLOSE button either on the front panel or
remote control, opening the disc storage door and exposing the
carousel slots.
OPEN/CLOSE
OPEN/
CLOSE
or
(Remote control)
2. To select a specified slot to load a disc, turn the DISC/TRACK
jog dial or press the / / / buttons to specify the slot
number, which is shown as the “DISC” number on the display.
The carousel rotates to bring the specified slot to the load/unload
position, which is in the center of the storage area.
OPEN/CLOSE
OPEN/
CLOSE
or
(Remote control)
DISC/TRACK
DOWN UP
+ 10DISC
–10DISC –1DISC + 1DISC
or
(Remote control)
