25
2 2
q 5 / 8 6
OK
CH
POWER
ACCESS SPECIAL
FUNCTION SCREEN
5
Press CH
5∞ or SHUTTLE
PLUS 5∞ to place the
arrow next to “SPECIAL
FUNCTION”, then press
OK.
ENABLE AV COMPU LINK
PLAYBACK
6
Press CH 5∞ or SHUTTLE
PLUS 5∞ to place the
arrow next to “AV
COMPU LINK”.
RETURN TO NORMAL
SCREEN
7
Press MENU as many times as necessary.
PERFORM AV COMPU LINK
PLAYBACK
8
Simply insert a cassette and press PLAY (if the cassette’s
record safety tab has been removed, playback begins
automatically). Linked components are turned on, and
the TV set to its VIDEO mode, automatically!
NOTE:
Connection varies depending on the type of TV you have.
Please refer to the TV’s instruction manual when making this
connection.
PLAY
FUNCTION
AUTO TIMER
SUPERIMPOSE
2ND AUDIO
AUDIO MONITOR
AUX INPUT
=SPECIAL FUNCTION
PRESS ( 5,∞), THEN (OK)
PRESS (MENU) TO END
SPECIAL FUNCTION
PAUSE
=AV COMPU-LINK
PRESS ( 5,∞) TO SELECT
PRESS (MENU) TO END
MENU
AV COMPU LINK
Television
Your VCR
AV COMPU LINK
AV COMPU LINK II
(VCR ONLY)
AUDIO
OUT
VIDEO
OUT
AV COMPU LINK Cable (not supplied)
VIDEO IN
AUDIO IN
Example
1 2
4 5
3
6
8
0
7 9
CH
MENU
OK
POWER
SHUTTLE PLUS
PLAY
