You can enjoy high-quality audio by connecting the unit's audio output to your amplifier or receiver.
• Connect the unit's AUDIO OUT (FRONT LEFT/RIGHT) to any line-level inputs (such as AUX, DVD, CD, etc.) of an audio
amplifier or receiver.
To connect to an audio amplifier or receiver
NOTE
• When using the unit with a stereo amplifier or receiver, make the “DOWN MIX” setting in “PREFERENCE 2” to “Lo/Ro” and the
Speaker setting in “SPK. SETTING” to “2 CH.” (see pages 60 and 62).
AUDIO
RIGHT
LEFT
IN
The unit
DIGITAL OUT
VIDEO OUT
AV COMPU LINK
S-VIDEO
VIDEO PCM / STREAM
COAXIAL OPTICAL
AV
COMP.
Y/C
Audio cable
(supplied)
White
Red
White Red
Amplifier or receiver
FRONT
REAR
SUBWOOFER CENTER
AUDIO OUT
RIGHT LEFT
RIGHT LEFT
