17
Quick Setup
INPUT 3 INPUT 4
S-VIDEO
Y
P B
P R
VIDEO
L
R
COMPONENT
AUDIO
Y
P B
P R
VIDEO
L
R
COMPONENT
AUDIO
VIDEO
L
R
AUDIO
L
R
AUDIO
TV Rear Panel
Speaker Speaker
Amplifier
INPUT 5
/ INPUT 1
AUDIO
AUDIO
OUT
1) Connect a white cable from the LEFT AUDIO OUTPUT on the back of the TV to the
LEFT AUDIO INPUT on the amplifier.
2) Connect a red cable from the RIGHT AUDIO OUTPUT on the back of the TV to the
RIGHT AUDIO INPUT on the amplifier.
Notes:
• Refer to your amplifier’s manual for more information.
• You can use AUDIO OUTPUT for your home theater system.
• If you have a device connected to INPUT-1 or INPUT-2, you will not be able to hear any
audio from the AUDIO OUT on the back of the TV.
Connecting to an External Amplifier
