14
1 Detergent dispenser drawer
2 Mains-on light
This light comes on when the “On/Off” button is
pressed, and goes out when it is pressed again.
3 “On/Off” button
Press this button to switch the machine on. Press it
again to switch the machine off.
4 “Spin” button
Press this button repeatedly to change the spin speed,
if you want your laundry to be spun at a speed
different from the one proposed by the washer-dryer
or to select position “Rinse hold”. The relevant light
will light up.
Spin speed
The following speeds are available for the different
fabrics:
• Cottons, linen:
500/700/900 max 1400 r.p.m.;
• Synthetics and wool:
500/700 max 900 r.p.m.;
• Delicates and “30 Minute wash”: 700 r.p.m.
“Rinse Hold” position
When RINSE HOLD option is selected, the last rinse
water is not emptied out, to prevent the fabrics from
creasing. When the programme has finished, the light
of the “Start/Pause” button goes out, the light of the
“Rinse hold” position and the “End” pilot light are
alight to indicate that the water must be emptied out.
The door is locked.
The Control Panel
1 2 3 4 5 6 9
10
7 8 11 12
Rinse hold
Prewash
Wash
Rinse
Rinse hold
Drain
Spin
Drying
End
Start/
Pause Spin Prewash
Delay
start Quick
On/Off
Extra
rinse
Automatic
dry
Time
dry
Extra dry
Store dry
Iron dry
Programme time
900
700
500
1400
JLBIWD1400
Synthetics
Cold
30°
40°
Wo
ol
Spin
Drain
Softeners
Rinse
Soak 30°
Delicates 30°
30 Minute wash
Delicates 40°
90°
Economy 60°
Economy 40°
60°
40°
30°
60°
40°
Economy 40°
Easy iron 40°
Cottons
Drying
Drying
Off
To empty out water there are 2 possibilities:
• Select programme “Drain” and then depress the
“Start/Pause” button:
The water is emptied out without spinning.
• Select the Spin programme : reduce the spin speed
by means of the relevant button and then depress
the “Start/Pause” button.
The water is emptied out and the laundry is spun at
the selected spin speed.
Important !
Before selecting the “Drain” or “Spin” programmes, the
selector dial must be positioned on Off (cancelling).
The “Rinse hold” option CANNOT be selected for
the automatic Washing & Drying programme.
5 “Option” buttons
Depending on the programme, different functions can
be combined. These must be selected after choosing
the desired programme and before depressing the
“Start/Pause” button.
When these buttons are pressed, the corresponding
pilot lights illuminate. When they are pressed again, the
pilot lights go out.
If an incorrect option is selected, the pilot lights flash
for about 2 seconds, an acoustic signal is heard and the
message Err is displayed.
Press these buttons to select the following options:
• “Prewash”: select this option if you wish your
laundry to be prewashed at 30°C max. before the
main wash (not available for Wool and “30
Minute wash”).
The prewash cycle ends with a short spin at 650 rpm
in programmes for cotton and synthetic fabrics,
whereas in the programme for delicate fabrics the
water is only drained. This option can be selected for
heavily soiled laundry.
