JVC GR-DVL9000 User Manual
Page 79

EN
79
%
Progressive Dial (PROGRESSIVE)
(
੬
pg. 30, 46)
Turn for Progressive Video Recording or Pro
Snapshot Recording.
^
Progressive Button (
੬
pg. 30, 46)
When this button is pressed, the camcorder starts
Progressive Mode Recording (high resolution).
When pressed during playback, a playback
snapshot is taken.
&
OPEN/EJECT switch (
੬
pg. 14)
Slide the switch down when loading/unloading a
tape.
*
Speaker (
੬
pg. 52)
During playback, the sound can be heard.
(
PUSH-OPEN button (
੬
pg. 14)
Press to open the LCD monitor.
)
Power dial (
੬
pg. 20)
Turning the camcorder on/off, recording or
playback is possible.
q
MENU button (
੬
pg. 33)
Press this button to make the Menu appear.
ON/OFF button (
੬
pg. 24)
Press and hold this button for more than approx.
1 second to make the indications appear on the
LCD monitor or the viewfinder.
w
Function Navigator Dial (Select Dial)
(
੬
pg. 24, 33)
Adjusts the brightness of the LCD monitor or
selects the Menu etc. Referred to in this manual
as “Select Dial”.
e
START/STOP button (
੬
pg. 20)
Starts recording or stops recording to make the
camcorder enter the record-standby mode.
r
Viewfinder (
੬
pg. 17)
Pull out when recording.
1
Zoom switch or volume switch (VOL.)
(
੬
pg. 26, 52)
Adjusts zoom during recording or the sound
volume during playback.
2
Grip strap (
੬
pg. 16)
3
Tally lamp
Lights during recording.
4
Remote sensor (
੬
pg. 54)
Receives the signal from the remote control.
When using the remote control, point it at the
remote sensor.
5
Lens cover
Opens when the viewfinder is pulled out or the
LCD monitor is opened fully.
6
Stereo microphone (
੬
pg. 70)
For use when recording or audio dubbing.
7
External microphone input connector
(MIC) (Stereo) (
੬
pg. 70)
An optional microphone can be connected.
8
JLIP (Joint Level Interface Protocol)
(DIGITAL STILL) output connector
(
੬
pg. 60)
Outputs the digital still image to a personal
computer.
9
EDIT jack (
੬
pg. 65)
Using an editing cable, connect to the remote
control or VCR.
0
RESET button (
੬
pg. 76)
When a malfunction occurs, press this button
after removing the power supply (battery etc.).
Pressing this button also resets the date/time or
various settings.
!
Stop button (5) (
੬
pg. 52)
Stops playback of the tape.
@
Play/Pause button (6/4) (
੬
pg. 52)
Plays back or stops the tape temporarily.
#
Fast-Forward button (3) (
੬
pg. 52)
Fast-Forwards the tape.
$
Rewind button (2) (
੬
pg. 52)
Rewinds the tape.
